Ліфт Basic X

Basic X lift

Electric lift with a traction drive.
The lift can be machine-room-less or with the machine room located on the top.
A model with a reinforced construction and a lift height of up to 120 m.
Primarily used for heavy-duty operations, such as industrial facilities, transporting automotive equipment, or large-sized cargos.

● Machine-room-less design.● With a machine room located on the top.● Central-type frame.● Load capacity ranging from 320 to 5000 kg.● 1:1, 2:1, 4:1 suspension options.● Speed ranging from 0.63 m/s to 4.0 m/s.● Lift height of up to 120 m.● Traction steel ropes from 8 mm to 10 mm.● Modularity of the construction allows for the use of various components.● Smooth ride quality due to multi-stage isolation and increased load-carrying capacity of elements.● High strength reserves for heavy panoramic cabins.● Energy-efficient operation.● Options: Lubrication-free guide rail movement using rollers.● Complies with the requirements of BS EN 81-20, BS EN 81-50, BS EN 81-21.
